Features

• Pinpoint Triggering provides the most flexible and highest performance triggering, with over 1400 combinations to address virtually any triggering situation
• Visual Trigger and Search precisely qualifies triggers and finds unique events in complex waveforms
• Advanced Search and Mark to find specific events in the entire waveform
• MyScope custom control windows and right mouse click menus for exceptional efficiency
• 53 automated measurements, waveform histograms, and FFT analysis for simplified waveform analysis
• TekVPI Probe Interface supports active, differential, and current probes for automatic scaling and units
• Optional serial triggering and analysis
• Automated Serial Triggering, Decode, and Search Options for I2C, SPI, CAN, LIN, FlexRay, RS-232/422/485/UART, MIL-STD-1553, and USB 2.0
• Automated Serial Analysis Options for MIPI D-PHY DSI-1 and CSI-2, 8b/10b, Ethernet, and PCI Express
• Clock Recovery from serial data streams
• 64-bit NRZ Serial Pattern Trigger for isolation of pattern-dependent effects up to 1.25 Gb/s
• Optional technology specific analysis
• Software Solutions provide built-in domain expertise for MIPI DPHY, Ethernet, Automotive Ethernet, MOST, and USB 2.0 Compliance Testing, Jitter, Timing, Eye Diagrams, Power, DDR Memory Bus Analysis, and Wideband RF
• Limit and Mask Testing provide quick insight into signal characteristics
• 12.1 in. (307 mm) bright XGA display with touch screen
