Features

• 3 independent controlled and isolated outputs: 32V/3.2A x 2, 2.5V/3.3V/5V/3.2A x 1, total 220W
• 5 digits Voltage, 4 digits Current Display, Minimum Resolution: 1mV/1mA
• Supports panel timing output functions
• 3 kinds of output modes: independent, series, parallel
• 100V/120V/220V/230V compatible design to meet the needs of different power grids
• Intelligent temperature-controlled fan, effectively reducing noise
• Clear graphical interface, with waveform display function
• Five internal groups of system parameter save/recall, supports data storage space expansion
• Provides PC software: Easypower; supports SCPI, Labview driver
• 4.3 inch true color TFT-LCD display
