Features

• Five inch high resolution capacitive touchscreen GUI
• Source and measurement resolution down to 10 fA and 100 nV
• Maximum display digits 6.5 (21,000,00 count)
• Maximum sampling rate is 100ksps, the sampling interval is 0.0005 PLC, and the maximum setting is 100 PLC
• Minimum trigger interval 10 μs
• Up to 100k points of internal storage space, supporting timestamps
• Voltage (±210 V) and current (± 3 A DC and ±10.5 A pulsed) sourcing capability
• Five basic functions voltage/current sourcing, voltage/current/resistance measurement
• Minimum programmable pulse width is 50 μs
• With arbitrary waveform generation and list scanning capabilities (minimum interval of 10 μs)
• Supports two-wire/four-wire measurement modes
• Supports SCPI remote control commands
• Settable output filter
• Configuration Interfaces USB Device (optional USB-GPIB adapter), USB Host, LAN
