Features

• Waveform capture rates up to 110,000 wfm/s (normal mode), and 480,000 wfm/s (sequence mode)
• Supports 256-level intensity grading and color temperature display modes
• Record length up to 250 Mpts
• Intelligent triggers: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern, Qualified and Video (HDTV supported). Trigger zone helps to simplify advanced triggering
• Serial bus triggering and decoder, supports protocols I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S, and MIL-STD-1553B
• Low background noise, supports 0.5 mV/div to 10 V/div voltage scales
• Segmented acquisition (Sequence) mode, dividing the maximum record length into multiple segments (up to 100,000) according to trigger conditions set by the user, with a very small dead time between segments to capture the qualifying event.
• History waveform record (History) function, the maximum recorded waveform length is 100,000 frames
• Automatic measurement function on 39 parameters, supports statistics with histogram, Gating measurement, Math measurement, History measurement, and Ref measurement
• 16 digital channels (optional) with maximum waveform capture rate up to 1.25 GSa/s, record length up to 62.5 Mpts
• 25 MHz function / arbitrary waveform generator, built-in multiple predefined waveforms
• Large 10.1 inch TFT-LCD display with 1024 * 600 resolution; Capacitive touch screen supports multi-touch gestures
• Supports external mouse and keyboard
• Multiple interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11, telnet, socket, web), Pass/Fail, Trigger Out, 10 MHz In, 10 MHz Out, VGA output
• Built-in web server supports remote control by the LAN port using a web browser
• Supports SCPI remote control commands
