Features

• Intelligent trigger: Edge, Slope, Pulse Width, Window, Runt, Interval, Timeout (Dropout), and Pattern
• Free Serial bus triggering and decoding: IIC, SPI, UART, RS232, CAN, and LIN
• Video triggers and supports HDTV
• Low background noise and 500 microV/div to 10 V/div voltage scales
• 10 types of one-button shortcuts, supports Auto Setup, Default, Cursors, Measure, Roll, History, Display/Persist, Clear Sweeps, Zoom, and Print
• Segmented acquisition (Sequence) mode, dividing the maximum record length into multiple segments (up to 80,000), according to trigger conditions set by the user, with a very small dead time segment to capture the qualifying event
• History waveform record (History) function, the maximum recorded waveform length is 80,000 frames
• Automatic measurement function on 38 parameters, supports Statistics, Gating measurement, Math measurement, History measurement, and Ref measurements
• 1 Mpts FFT
• True measurement and math can use all 14 Mpts of memory
• Preset key can be customized for user settings or factory defaults
• Security Erase Mode
• High-speed hardware based Pass/Fail function
• Multiple interface types: USB Host, USB Device (USB-TMC), LAN (VXI-11), Pass / Fail, Trigger Out
• Supports SCPI remote control commands
• Multi-language display and embedded online help
