Features

• 5 inch true color TFT-LCD display with a resolution of 800 x 480, paired with a touchable screen and a brand-new UI
• Real 6.5 digit (2,200,000 count) readings resolution
• Up to 50k rdgs/s of measurement speed, support a maximum sampling interval of 100 PLC and a minimum sampling interval of 0.001 PLC
• 512 MB RAM, capable of saving up to 2M readings for caching, support timestamp
• 256 MB Nand Flash, supports storage of various types of files such as readings, images, configuration files
• 4 trigger modes: auto trigger, single trigger, external trigger and level trigger
• 4 display modes: numerical, bar meter, trend chart and histogram
• DC measurements support autozero functions
• True-RMS AC Voltage and AC Current measurement
• Support automatic switching between 10 A high current and 3 A low current measurement modes, and can be tested up to 30 A when paired with an external shunt
• Support RTD, thermocouple and user-defined sensor
• Support dual display and probe hold functions
• Support standard SCPI remote control commands
• Equipped with EasyDMM-X host computer control and sampling software
• Communications interface: USB Device (optional USB-GPIB adapter), USB Host, LAN
• Support BNC VMC output, Trigger input
• Support VNC, Web-server
• Chinese and English menu, and built-in help system for easy information retrieval
