Features

• Dual-channel, maximum output frequency 60 MHz, maximum output amplitude 20 Vpp
• 1 GSa/s digital-to-analog converter sampling rate, 16-bit vertical resolution
• Innovative TrueArb technology, based on a point-by-point architecture, supports any 24pts ~ 8Mpts Arb waveform with a sampling rate in range of 1 μSa/s ~ 250 MSa/s
• Supports sequence wave playback function, maximum storage depth per channel 8 Mpts
• Innovative EasyPulse technology, capable of generating lower jitter Square or Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment
• Multi-pulse output function can be used to measure the switching parameters of power equipment and evaluate its dynamic characteristics
• Supports PRBS up to 40 Mbps
• Plenty of analog and digital modulation types: AM, DSB-AM, FM, PM, FSK, ASK, PSK and PWM
• Sweep and Burst function
• Harmonic function
• Waveform Combining function
• Waveform Combining function
• 196 built-in arbitrary waveforms
• Built-in WebServer supports instrument control via web browser
• Standard interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11)
• 4.3 inch LCD display
