Features

• Based on the brand new self-developed Centaurus technical platform
• 12 bit resolution, 4 analog channels, and 1 external trigger channel
• Standard configuration of 16 digital channels (required to purchase the logic analyzer probe)
• Real-time sample rate up to 2 GSa/s
• Max. memory depth 500 Mpts
• Vertical sensitivity up to 200 μV/div
• Max. waveform capture rate of 1,000,000 wfms/s (in fast recording mode)
• Arbitrary/Function Waveform Generator (optional), power analysis, histogram, digital signal analysis, Bode plot, and protocol decodings
• Search and navigation functions enable users to quickly search for the signals with exceptions and locate them accurately
• Brand new Flex knob brings friendly user experience
• Standard configuration of USB Device, USB Host, LAN, HDMI interfaces
• Battery pack-powered, convenient to charge anytime and anywhere, providing great feasibility for measurement
• Online upgrade
• Standard configuration of the photoelectric encoder operating knob to improve the service life of the instrument
• 256-level intensity grading display, with digital real-time fluorescence technology
• 10.1 inch, 1280x800 high-definition touch screen
