Features

• Based on the brand new self-developed Centaurus technical platform
• 12-bit resolution, up to 16-bit in high resolution mode
• Max. 1 GHz bandwidth, 8 analog channels, and 1 external trigger channel
• Real-time sample rate: up to 4 GSa/s
• Max. memory depth 500 Mpts
• Vertical sensitivity up to 100 μV/div
• Maximum waveform capture rate of 1,000,000 wfms/s in fast recording mode
• Search and navigation function helps users quickly search for the signals with exceptions and locate them accurately
• Brand new Flex knob brings friendly user experience
• Standard configuration of USB Device, USB Host, LAN, HDMI interfaces
• Battery pack-powered, convenient to charge anytime and anywhere, providing a great feasibility for measurement
• Online upgrade
• Standard configuration of the photoelectric encoder operating knob for all the series to improve the service life of the instrument
• 256-level intensity grading display, with digital real-time fluorescence technology
• 10.1 inch 1280x800 high-definition touch screen
