Features

• 4.3 inch, 16 M true color TFT LCD
• 1 GSa/s sample rate, 14 bits resolution
• Support an external power amplifier (optional) that can be configured online
• Support frequency hopping (optional) with hopping interval up to 80 ns and arbitrary editing frequency hopping patterns
• 14 standard waveform functions: Sine, Square, Ramp, Pules, Noise, Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Haversune, Lorentz, Dual Tones and DC.
• Rise/Fall Time of the Pulse could be adjusted separately
• Enable to edit arbitrary waveform up to 512 kpts and output arbitrary waveforms up to 128 Mpts
• Support AM, FM, PM, ASK, FSK, PSK and PWM modulations
• Support user-defined IQ vector signal modulation and IQ baseband/IF source output
• Support Frequency Sweep and Burst output
• Abundant I/O: waveform output, synchronous signal output, modulation input, 10 MHz clock input/output, trigger input/output
• Enable to store and recall waveform data and instrument state, and support versatile file types
• Plenty of standard interfaces: double USB hosts, USB device, LAN, GPIB
• Seamlessly interconnected with Rigol USB-TMC digital oscilloscopes for loading and reappearing waveforms
• Support USB flash device storage for FAT files
• Provides powerful waveform editing PC software
