Rigol DG5351 Function/Arbitrary Waveform Generator - New
$10,626.00
SKU
200119034-new
350 MHz, 1 Ch Function/Arbitrary Waveform Generator
Features
- 4.3 inch, 16 M true color TFT LCD
- 1 GSa/s sample rate, 14 bits resolution
- Support an external power amplifier (optional) that can be configured online
- Support frequency hopping (optional) with hopping interval up to 80 ns and arbitrary editing frequency hopping patterns
- 14 standard waveform functions: Sine, Square, Ramp, Pules, Noise, Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Haversune, Lorentz, Dual Tones and DC.
- Rise/Fall Time of the Pulse could be adjusted separately
- Enable to edit arbitrary waveform up to 512 kpts and output arbitrary waveforms up to 128 Mpts
- Support AM, FM, PM, ASK, FSK, PSK and PWM modulations
- Support user-defined IQ vector signal modulation and IQ baseband/IF source output
- Support Frequency Sweep and Burst output
- Abundant I/O: waveform output, synchronous signal output, modulation input, 10 MHz clock input/output, trigger input/output
- Enable to store and recall waveform data and instrument state, and support versatile file types
- Plenty of standard interfaces: double USB hosts, USB device, LAN, GPIB
- Seamlessly interconnected with Rigol USB-TMC digital oscilloscopes for loading and reappearing waveforms
- Support USB flash device storage for FAT files
- Provides powerful waveform editing PC software
