Features

• Adjustable slew rate
• Voltage monitor terminal for monitoring high voltage
• Equipped with 6 operation modes (CC, CR, CV, CP, CC+CV, CR+CV)
• Protection for overvoltage, overcurrent, overpower, overheat, undervoltage, and reverse connection
• Can connect a maximum of 5 like units in parallel when booster unit is not used (max 5kW, 250A)
• To achieve a large capacity system with less space and low cost, the PLZ1004WH has an expandable option PLZ2004WHB booster unit. Using 1 PLZ1004WH as a master unit, a maximum of 4 booster units can be parallel connected (max 9kW, 450A)
• Standard Interfaces: USB, GPIB, and RS-232C
