Features

• Precision multimeter with 3½- to 7½-digit resolution
• Capture and display waveforms or transients with 1 MS/sec digitizer
• Large internal memory buffer; store over 11 million readings in standard mode or 27.5 million in compact mode
• 14 PPM basic one-year DCV accuracy
• 100 mV, 1 Ω, and 10 μA ranges offer the sensitivity needed for measuring low level signals such as portable device sleep mode currents
• Make accurate low resistance measurements with offset compensated ohms, four-wire, and dry circuit functions
• Auto-calibration feature improves accuracy and stability by minimizing temperature and time drift
• Display more with five-inch, high resolution touchscreen interface
• Readings and screen images can be saved quickly via the front panel USB memory port
• Multiple connectivity options: GPIB, USB, and LXI compliant LAN interfaces
• Two-year specifications enable longer calibration cycles
