Instek LCR-6002 LCR Meter - New

$1,093.00

SKU

200108142-new

High Precision LCR Meter, 10 Hz to 2 kHz

Optional

GRA-422 - Rack Mount Kit + $50.00

LCR-05 - Test Fixture for Axial and Radial Lead Components + $243.00

LCR-07 - Test Fixture Two-Wire with Alligator Clips + $121.00

LCR-08 - Test Fixture (Tweezers) for SMD/Chip Components + $333.00

LCR-15 - Test Fixture for SMD/Chip Components (0201 to 1812) + $225.00

LCR-16 - Test Fixture +/-45V DC Bias Voltage Box + $1,120.00

LCR-17 - Test Fixture +/-2.5A DC Bias Current Box + $482.00

Qty

Basic accuracy: 0.05%
Measuring speed up to 25ms (max)
Full frequency range or spot OPEN/SHORT
16 major/secondary parameter measurement combinations and two additional monitoring parameters (maximum four different parameters can be shown simultaneously)
DCR measurement and internal D.C. bias voltage (+/-2.5V)
PASS/FAIL judgment
Auto Level Control (ALC) function
BIN function provides 9BIN and 1AUX, total 10BIN
10 steps listed tests to select different frequency, voltage, and current criteria
Standard interface: RS-232C, Handler, and USB storage
Compact size, ideal for automatic equipment (2U, 1/2 Rack)
3.5 inch color LCD display

More Information

Accessories

Options

Option Code	Description
GRA-422	Rack Mount Kit
LCR-05	Test Fixture for Axial and Radial Lead Components
LCR-07	Test Fixture Two-Wire with Alligator Clips
LCR-08	Test Fixture (Tweezers) for SMD/Chip Components
LCR-15	Test Fixture for SMD/Chip Components (0201 to 1812)
LCR-16	Test Fixture +/-45V DC Bias Voltage Box
LCR-17	Test Fixture +/-2.5A DC Bias Current Box
