Features

• 4-in-1 Model Capable of Performing AC Withstanding, DC Withstanding, Insulation Resistance, and Ground Bond Tests
• 500VA AC Test Capacity
• 240 x 64 Ice Blue Dot Matrix LCD
• Sweep Function for DUT characteristic analysis
• Manual/Auto Mode
• Function Key for quick selecting
• High intensity flash for Caution and Status indication
• Safety INTERLOCK function
• Zero Crossing Turn-On Operation
• Controllable Ramp-up Time
• High resolution: 1 uA for measuring current, 2V for setting voltage
• PWM amplifier to enhance the power efficiency and reliable testing
• Max 100 memory block for test condition (step) setting - Each step can be named individually
• Remote terminal on the front panel for start and stop control
• Interface: RS-232C, USB device, Signal I/O, and GPIB (optional)
