Features

• 1 GHz Bandwidth, 2 Input Channels
• 5 GSa/s Real-time Sampling Rate(half channels); 2.5 GSa/s Real-time Sampling Rate (all channels)
• Per Channel 200 Mpts Memory Depth
• 200,000 wfm/s of Waveform Update Rate
• 490,000 Segments of Segmented Memory and the Waveform Search Function to Optimize the Efficiency of Record Length
• Zoom Window and Play/Pause Rapidly Navigate the Waveforms
• 38 sets of Automatic Measurement Offer Various Measurement Selections
• High resolution acquisition mode
• I2C/SPI/UART/CAN/LIN Serial Bus Trigger 2 and Decoding Functions
• Dual Channel Spectrum Analyzer (DC to 2.5 GHz) with spectrogram
• Dual Channel 25MHz Arbitrary Waveform Generator
• Optional 13 Sets of Power Analysis Measurements
• Optional 16 Digital Channels with a Logic Analyzer(MSO)
• Flexible Remote Control Connectivity (Standard: USB/LAN/RS-232; Option: GPIB)
• 10.2 inch 800 x 480 TFT LCD Display
